CNC Turning

Turning is a method of cutting the workpiece on the lathe by rotating the workpiece relative to the tool. It is suitable for machining revolving surfaces. Most workpieces with revolving surfaces can be processed by turning, such as inner and outer cylindrical surfaces, inner and outer conical surfaces, end faces, grooves, threads, and revolving forming surfaces.



Zhongde, as a professional CNC machining company in China, supplies customized precision CNC turning and milling for all your requirements, such as quick turn production machining, with affordable prices and considerate service.



Our wide range of CNC lathes and turning centers in China will allow you to produce high-precision, high-standard CNC machining plastic parts, and metal parts. We have many kinds of materials and different surface treatments for you to choose from. Get a quote immediately and we will give you the most competitive price.

Home » Services » CNC Machining » CNC Turning

Size of CNC Turning

Below table shows the size of CNC Turning parts we usually make. If you need a larger size, we can also help you achieve it.

Size Metric Inch
Length 2500 98.4
Width 2000 78.7
Height 1500 59

Available Material of CNC Turning

In addition to the general materials listed below, Zhongde, a reputable company specializing in cnc machining and metal stamping service, can also modify the materials according to the special needs of customers. Our professional engineers will adjust the raw material formula to meet the unique conditions of use.

CNC Metals

  • Aluminum

  • Copper

  • Stainless Steel

  • Brass

  • Carbon Steel

  • Steel Alloy

CNC Plastics

  • ABS

  • Nylon 6

  • PVC

  • HDPE

  • PC | Polycarbonate

  • PP | Polypropylene

  • POM | Delrin

  • LDPE

  • UHMWPE

  • PTFE

Service

Injection Molding

  • Plastic Injection Molding
  • Rubber Injection Molding
  • Overmolding & Insert Molding

Compression Molding

Cast Molding

CNC Machining

  • CNC Milling
  • CNC Turning

Metal Stamping

3D Printing

  • Fused Deposition Modeling
  • Selective Laser Sintering

Material Selection

Color Option

Surface Finishing

Assembly & Packaging

Custom Products

Custom Plastic Parts

  • Plastic Parts
  • Plastic Bonding Metal Parts

Custom Rubber Parts

  • Rubber Parts
  • Rubber Bonding Metal Parts
  • Rubber With Fabric Parts
  • Rubber Bonding Plastic Parts

Custom TPE Parts

  • TPE Parts

CNC Machining Parts

  • Plastic CNC Machining Parts
  • Metal CNC Machining Parts

3D Printing Parts

  • Plastic 3D Printing Parts
  • Metal 3D Printing Parts
  • Assembly Parts

CNC Turning Surface Finishing

CNC turning Parts surface finish is critical to a successful part design and it is used for aesthetic and functional reasons in injection molded parts for engineering products. The surface finish improves the look and the feel of a product as the perceived value and quality of the product increase with a suitable surface finish.

Different grades of surface finishing chart.

Name

Description

Material Compatibility

Color

Link


As Machined

For as machined all sharp edges are removed and parts are deburred. Tool marks are visible.

All plastics and metals

Uniform matte of raw material color


Smoothing

A finishing CNC machining operation can be applied to the part to reduce its surface roughness. Machine marks are less evident but still visible.

All plastics and metals

Uniform matte of raw material color


Bead Blasting

Bead blasting adds a uniform matte or satin surface finish on a machined part, removing the tool marks. This is used mainly for visual purposes and comes in several different grits which indicate the size of the bombarding pellets.

All metals

Uniform matte of raw material color


Powder Coating

Powder coating is a strong, wear-resistant finish that is compatible with all metal materials and can be combined with a bead blasting to create parts with smooth and uniform surfaces and excellent corrosion resistance.

All metals

Black or any RAL code or Pantone number


Anodizing Color(Type II)

Type II anodizing is mainly used to produce parts with a uniform, aesthetically pleasing surface and provides good corrosion and limited wear resistance.

Aluminum alloys

Black, clear or any RAL code or Pantone number


Anodizing Hardcoat(Type III)

Type III anodizing provides excellent corrosion and wear resistance, suitable for functional applications.

Aluminum alloys

Black or clear


Electropolishing

Electropolishing is an electrochemical process used to polish, passivate and deburr metal parts. It is useful to reduce surface roughness.

All metals

Natural metal color


Black Oxide

Black oxide is a conversion coating used to improve corrosion resistance and minimize light reflection.

Stainless steel and copper alloys

Black


Chromate Conversion Coating (Alodine/Chemfilm)

Chromate conversion coating is used to increase the corrosion resistance of metal alloys while maintaining their conductive properties.

Aluminum and copper alloys

Clear or yellow


Brushing

Brushing is produced by polishing the metal with grit resulting in a unidirectional satin finish. Not advisable for applications where corrosion resistance is required.

All metals

Natural metal color
